Page #37 background imageLoading...
Page #37 background image
Connecting the Console Port of the Device
Before You Begin
Before you can configure the device for basic operations, you need to connect it to a PC that uses a VT-100
terminal emulation program (such as HyperTerminal, ProComm, Minicom, or Tip).
Step 1
Connect one end of a null-modem serial cable to the device's RJ-45 console port and the other end to your PC's serial
port.
Step 2
Plug the AC power cord into the device and a grounded 100 to 240 VAC, 50/60-Hz electrical outlet. Turn on the power
supply. The bootup script displays operating system software initialization (code download and power-on self-test
verification) and basic configuration. If the device passes the power-on self-test, the bootup script runs the configuration
wizard, which prompts you for basic configuration input.
Step 3
Enter yes. Proceed with basic initial setup configuration parameters in the CLI setup wizard. Specify the IP address for
the service port which is the gigabitethernet 0/0 interface.
After entering the configuration parameters in the configuration wizard, you can access the Web GUI. Now, the device
is configured with the IP address for service port.
Logging On to the Web GUI
Enter the device IP address in your browsers address bar. For a secure connection, enter https://ip-address. For a less
secure connection, enter http://ip-address.
Enabling Web and Secure Web Modes
Step 1
Choose Configuration > Switch > Management > Protocol Management > HTTP-HTTPS.
The HTTP-HTTPS Configuration page appears.
Step 2
To enable web mode, which allows users to access the device GUI using http://ip-address, choose Enabled from the
HTTP Access drop-down list. Otherwise, choose Disabled. Web mode (HTTP) is not a secure connection.
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 15
Using the Web Graphical User Interface
Connecting the Console Port of the Device
