PurposeCommand or Action
Example:
Device(config-if)# exit
Device(config-if)# end
(Optional) Displays information about the status and configuration
of IGMP and multicast routing on interfaces.
show ip igmp interface [type number]
Example:
Device# show ip igmp interface
Step 6
(Optional) Displays the multicast groups with receivers that are
directly connected to the device and that were learned through
IGMP.
show ip igmp groups
Example:
Device# show ip igmp groups
Step 7
Configuration examples for IGMP State Limit
Configuring IGMP State Limiters Example
The following example shows how to configure IGMP state limiters to provide multicast CAC in a network
environment where all the multicast flows roughly utilize the same amount of bandwidth.
This example uses the topology illustrated in the figure.
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
354 OL-29890-01
IP Multicast Optimization: IGMP State Limit
Configuration examples for IGMP State Limit

Cisco Catalyst 3650 Specifications

General

Switching Capacity	160 Gbps
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Device Type	Switch
Form Factor	Rack-mountable
Layer	Layer 3
DRAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3650
Ports	24 or 48 10/100/1000 Ethernet ports
Stacking	Yes
Power over Ethernet (PoE)	Yes
Power Supply Options	350W AC
VLANs	4094
