show ipsla mpls lsp-monitor lpd
To display LSP Path Discovery (LPD) operational status, use the show ipsla mpls lsp-monitor lpd command
in EXEC mode.
show ipsla mpls lsp-monitor lpd {statistics [group-ID| aggregated group-ID]| summary group}
Displays statistics for the specified LPD group,
including the latest LPD start time, return code,
completion time, and paths.
statistics group-ID
Displays the aggregated statistics of the LPD group.
aggregated group-ID
Displays the current LPD operational status, which
includes LPD start time, return code, completion time,
and all ECMP path information.
summary group- ID
Command Default
None
Command Modes
EXEC
Command History
ModificationRelease
This command was introduced.Release 3.6.0
Usage Guidelines
For the aggregated group ID, a maximum of two buckets are allowed.
Task ID
OperationsTask ID
readmonitor
Examples
The following sample output is from the show ipsla mpls lsp-monitor lpd statistics command:
RP/0/0/CPU0:router# show ipsla mpls lsp-monitor lpd statistics 10001
Group ID: 100001
Latest path discovery start time : 00:41:01.129 UTC Sat Dec 10 2005
Latest path discovery return code : OK
Latest path discovery completion time (ms): 3450
Completion Time Values:
NumOfCompT: 1 CompTMin: 3450 CompTMax : 3450 CompTAvg: 3450
Cisco IOS XR System Monitoring Command Reference for the Cisco XR 12000 Series Router, Release 4.1
226 OL-24735-01
IP Service Level Agreement Commands
show ipsla mpls lsp-monitor lpd
