Citrix SD-WAN Platforms
• To enable access on 1/5, execute one of the following commands.
– enable 1/5 # Works for GBE transceivers only if already configured.
– enable 1/5 100 # - Works only for FE transceivers
– enable 1/5 1000 # - Works only for GBE transceivers
– enable 1/5 100 172.217.43.2 # - For FE transceivers and assumes a user changes the
default IP to an IP in 172.217.43.0/24
• enable 1/5 1000 172.217.43.2 # - For GBE transceivers and assumes a user changes the de-
fault IP to an IP in 172.217.43.0/24
Note:
Enabling management access on 1/5 automatically disables management access on
1/6, and vice versa.
• To disable access to the management:
– Log in appliance CLI via ssh admin@(IP address)
– Run: sfp_access
– Run: disable
• To show the status:
– Log in appliance CLI via ssh admin@(IP address)
– Run: sfp_access
– Run: status
• Ensure that you disable the management access once configuration is done.
• When the appliance is rebooted, the management access is disabled automatically.
• When virtual service is restarted, the management access remains configured until enable
or disable operation is done.
• When the appliance is disabled, the management access to the SFPs is lost.
• When the appliance is re-enabled, the management access is regained.
3. To configure E1 or T1 type for SFP transceiver:
• The client machine must be in the same IP subnet as the appliance management subnet.
• The client machine must have a route to the subnet of SFP transceiver IP address,
192.168.205.0/24, with the appliance management IP as the gateway.
• Open a browser and visit SFP transceiver management
• Default user name: su
• Default password: 1234
• To configure Interface Type (E1 or T1), navigate to Configuration > Physical Ports and
choose E1 or T1 from the drop down menu, and click Save button.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 151
