Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
The Citrix SD-WAN VPXL-SE platform can handle up to 256 virtual paths when provisioned as an MC-
N/RCN.
Following are the configuration requirements for the VPXL-SE platform.
• 16 GB memory and 16 CPU cores.
• 250 GB of HDD.
The number of virtual paths and dynamic virtual paths that the SD-WAN VPXL-SE platform can handle,
irrespective of the appliance role (MCN, RCN, or Client) is as follows:
Memory Less than 16 GiB More than 16 GiB
Virtual Path 16 256
Dynamic Virtual Path 8 32
Configuring Citrix SD-WAN VPXL-SE
To configure SD-WAN VPXL-SE:
1. Import the SD-WAN VPX-SE base image (.ova or.xva template). Do not Power ON the Virtual
machine.
2. Modify the VM resources for Memory to 16 GB RAM, CPU to 16vCPUs and hard disk size to 250
GB.
3. Add the required NIC interfaces to the VM (for LAN and WAN interfaces).
4. Power ON the VM.
5. Now, SD-WAN VPX-SE would operate as a VPXL-SE platform model.
6. In case the VM is already Powered ON, before modifying the VM resources, you must perform
Reimage Virtual WAN Appliance Soware under Configuration > System Maintenance> Up-
date Soware, and use the cb-vw_CBVPXL_version.tar.gz image file.
Note
Ensure to clear options that mention to Power on the Virtual machine, aer the VM provision-
ing/import process is complete.
How to upgrade VPX-SE to VPXL-SE
To upgrade VPX-SE to VPXL-SE:
1. The VPX-SE should have been installed with an SD-WAN base release version of 9.3.0 or higher.
2. Backup and save your existing configuration, if the VPX-SE you are upgrading is an MCN.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 397

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
