Citrix SD-WAN Platforms
Wall mount the appliance
The Citrix SD-WAN 110-SE appliance can be wall mounted by placing and adjusting the appliance screw
slots on the wall screws.
Use two wall mount screws with the following dimensions:
• Screw Length: 12 mm
• Screw out of wall: 5.5 mm
• Screw head: 6.0 mm ~ 7.5 mm
• Screw body: 3.5 mm
Rack mount the appliance
1. Fix the shelf to the rack with the provided screws.
2. Install the chassis. Place the appliance screw slots on the positioning screws on the shelf and
slide it, to lock it into position.
