Citrix SD-WAN Platforms
Figure 3. 210 SE (LTE) front panel with antenna
LED Description
Ethernet Copper Ports LED Active/Link: Green
Speed: 1000 Orange
Speed 100: Green
Speed 10: o
Bypass LEDs Normal Mode: Green
Bypass Mode: Orange
Ethernet Fiber Ports Active/Link: Green
Speed: 1000: Orange**
System and Data LEDs Sys: Power on: Green
© 1999-2021 Citrix Systems, Inc. All rights reserved. 75
