Citrix SD-WAN Platforms
Interface Port Labels Type Description
Management RJ-45 A copper Ethernet
(RJ45) management
port. The
management port is
used to connect
directly to the
appliance for system
administration
functions. You can
use this port for initial
provisioning of
Virtual WAN.
2 1/4 and 1/5 SFP and Ethernet
(combination ports)
Used as a
combination of SFP
and Ethernet one
each on the top and
bottom.
3 USB 2 USB ports
4 Console RS-232 serial An RS232 serial
console port
5 Reset Reset button Consult Citrix
technical support for
more information.
6 Power Power button Power button to
power on or o the
appliance. Press the
switch for five
seconds to switch o
the power.
7 Power supply DC Power supply Single power adapter.
Power rating: 40 W,
voltage: 12 V, and
current: 3.33 A.
8 Antenna connectors Male connectors Connectors for
antenna
© 1999-2021 Citrix Systems, Inc. All rights reserved. 77
