InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 63
AMF26-P-2.4 Reference Guide.pdf
AL Common Wrn
The output closes when any warning alarm appears.
The output opens, if:
x No warning alarm is active and
x FAULT RESET is pressed
AL Common Sd
The output closes when any shut-down alarm appears.
The output opens, if:
x No Sd alarm is active and
x FAULT RESET is pressed
AL Common BOC
The output closes when any BOC alarm appears.
The output opens, if:
x No BOC alarm is active and
x FAULT RESET is pressed
AL Common Fls
The output closes when any Sensor Fail alarm appears.
The output opens, if:
x No warning alarm is active and
x FAULT RESET is pressed
AL AI1 Sd
The output closes if the oil pressure (if configured to the first analog input) shutdown alarm activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
AL AI1 Wrn
The output closes if the oil pressure (if configured to the first analog input) warning alarm activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
Hint:
AI1 is dedicated, but not used by default for Oil Pressure measurement.
AL AI2 Sd
The output closes if the engine temperature (configured to the second analog input) shutdown alarm
activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
AL AI2 Wrn
The output closes if the engine temperature (configured to the second analog input) warning alarm
activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
