8-6 Compaq AlphaServer ES40 Service Guide

8.1.2 FRU Locations

Figure 8–1 and Figure 8–2 show the location of FRUs in the pedestal

and rackmount configurations.

Figure 8–1 FRUs — Front/Top (Pedestal/Rack View)

PK0285

Memory DIMMs

CPU Cards

Fans

OCP

Secondary

Drive Cage

Primary

Drive Cage

CD-ROM Drive

Floppy Drive

PCI

Backplane
