Registers D-43
D.19 Console Data Log Event Environmental Error
Logout Frame (680 Uncorrectable)
Compaq Analyze uses the logout frame in Table D–18 for its
decomposition of all 680 system environmental uncorrectable error
frames.
Table D–18 Console Data Log Event Environmental Error Logout
Frame (680 Uncorrectable)
63 56 55 48 47 40 39 32 31 24 23 16 15 8 7 0 Offset (Hex)
Revision (1) Type (3) Class (12) Length (80) 00000000
Processor WHAMI 00000008
Retryable/Second Error Flags Frame Size 0070) 00000010
System Area Offet(0020) EV6 Area Offset(0020
1
) 00000018
Machine Check Frame Revision Machine Check Code (206) 00000020
Software Error Summary Flags 00000028
Cchip CPUx Device Interrupt Request Register (DIRx System Primary CPU
Fault Watcher)
00000030
Environ_QW_1 (TIG System Management Information Register (SMIR)) 00000038
Environ_QW_2 (TIG CPU Information Register (CPUIR)) 00000040
Environ_QW_3 (TIG Power Supply Information Register (PSIR)) 00000048
Environ_QW_4 (System_PS/Temp/Fan_Fault - LM78_ISR ) 00000050
Environ_QW_5 (System_Doors) 00000058
Environ_QW_6(System_Temperature_Warning) 00000060
Environ_QW_7(System_Fan_Control_Fault) 00000068
Environ_QW_8(Fatal_Power_Down_Codes) 00000070
Environ_QW_9(Environmental Reserved 1) 00000078
NOTE: Only Environ_QW_8 contains valid error state capture. All other
Environ_QW_1-7, 9 will be zeroed.
1
Per Alpha SRM requirement.
