Registers D-45
D.21 Environmental Error Logout Frame
(680 Correctable)
Table D–20 shows Environ_QW_1:7 and Environ_QW_8 error state
capture information from DPR locations A0:A9 and BD:BF,
respectively.
Table D–20 Environmental Error Logout Frame
63 56 55 48 47 40 39 32 31 24 23 16 15 8 7 0 Offset (Hex)
Retryable/Second Error Flags Frame Size 0070) 00000000
System Area Offet(0018) EV6 Area Offset(0018
1
) 00000008
Machine Check Frame Revision(1) Machine Check Code (206) 00000010
Software Error Summary Flags 00000018
Cchip CPUx Device Interrupt Request Register (DIRx System Primary CPU
Fault Watcher)
00000020
Environ_QW_1 (TIG System Management Information Register (SMIR)) 00000028
Environ_QW_2 (TIG CPU Information Register (CPUIR)) 00000030
Environ_QW_3 (TIG Power Supply Information Register (PSIR)) 00000038
Environ_QW_4 (System_PS/Temp/Fan_Fault - LM78_ISR ) 00000040
Environ_QW_5 (System_Doors) 00000048
Environ_QW_6(System_Temperature_Warning) 00000050
Environ_QW_7(System_Fan_Control_Fault) 00000058
Environ_QW_8(Fatal_Power_Down_Codes) 00000060
Environ_QW_9(Environmental Reserved 1) 00000068
NOTE: Only Environ_QW_1–7 contain valid error state capture. All other
Environ_QW_8,9 will be zeroed.
1
Per Alpha SRM requirement.
