8-32 Compaq AlphaServer ES40 Service Guide
8.10
PCI Cards
Figure 8–15 Installing or Replacing a PCI Card
PK0245
2
3
1
WARNING: To prevent fire, use only modules with current
limited outputs. See National Electrical Code NFPA 70 or Safety
of Information Technology Equipment, Including Electrical
Business Equipment EN 60 950.
V @ >240VA
WARNING: High current area. Currents exceeding
240 VA can cause burns or eye injury. Avoid
contact with parts or remove power prior to access.
