5-16 Compaq AlphaServer ES40 Service Guide
5.3.1 Error Logging and Event Log Entry Format
The operating system error handlers generate several entry types.
Entries can be of variable length based on the number of registers
within the entry.
Each entry consists of an operating system header, several device frames, and
an end frame. Most entries have a PAL-generated logout frame, and may
contain frames for CPU, memory, and I/O.
Table 5–3 shows an event structure map for a Windows NT system uncorrect-
able PCI target abort error.
NOTE: See Appendix D for the source data Compaq Analyze uses to isolate to
the FRUs.
