FRU Removal and Replacement 8-21
WARNING: Hazardous voltages are contained within the
power supply. Do not attempt to service. Return to factory for
service.
The power supply is a hot-plug component. As long as the system has a
redundant supply, you can replace a supply while the system is running.
Removing a Power Supply
1.
Unplug the AC power cord.
2.
Loosen the three Phillips screws
➊ that secure the power supply bracket.
(Do not remove the screws.) Remove the bracket
➋.
3.
Loosen the captive screw on the latch
➌ and swing the latch to unlock the
power supply.
4.
Pull the power supply
➍ out of the system.
NOTE: When installing an additional supply, remove the screw and blank
cover ➎ on the slot into which you are installing the supply.
Verification
1.
Plug the AC power cord into the supply. Wait a few seconds for the POK
LED to light.
2.
Check that both power supply LEDs are lit.
To Next Page
