FRU Removal and Replacement 8-23
The fans are hot-plug components. You can replace individual fans while the
system is running.
WARNING: Contact with moving fan can cause
severe injury to fingers. Avoid contact or remove
power prior to access.
Replacing Fans
1.
Remove the cover from the fan area (fans
➎ and ➏) or the PCI card cage
(fans
➊,➋,➌, and ➍).
2.
Pull the pop-up latch to unlock it, and lift the fan out of the system. Fan
➌
has no pop-up latch. It is held in place by fan ➍.
3.
Install the new fan, taking care to align it as it slides in. Press the pop-up
latch to lock the fan in place.
4.
Replace the cover to the fan area or the PCI card cage.
Verification — RMC
1.
Invoke the remote management console.
2.
Enter the env command to verify the fan status.
