FRU Removal and Replacement 8-29
WARNING: Memory DIMMs have parts that operate at high
temperatures. Wait 2 minutes after power is removed before
touching any module.
V @ >240VA
WARNING: High current area. Currents exceeding
240 VA can cause burns or eye injury. Avoid
contact with parts or remove power prior to access.
CAUTION: DIMMs come in two types, stacked or unstacked. See Chapter 6
before replacing DIMMs.
Replacing DIMMs
You must shut the system down before adding or replacing DIMMs.
1.
Remove the fan cover and the system card cage cover.
2.
Release the clips
➊ that secure the MMB to the system backplane and slide
out the MMB.
3.
Release the clips
➋ on the MMB slot containing the bad DIMM and remove
the DIMM
➌.
Continued on next page
