Registers D-53
Table D–21 Bit Definition of Logout Frame Registers (Continued)
ID Bit Field Text Translation Description
DIRx <63>
<62>
<61>
<60>
<59>
<58>
<57:56>
<55>
<54>
<53>
<52>
<51>
<50>
<49>
<48>
<47:44>
<43:40>
<39:36>
<35:32>
<31:28>
<27:24>
<23:20>
<19:16>
<15:12>
<11:8>
<7:0>
Internal Cchip asynchronous error [i.e.NXM] (IRQ0)
P0_Pchip error (IRQ0)
P1_Pchip error (IRQ0))
P2_Pchip error (future designs) (IRQ0)
P3_Pchip error (future designs) (IRQ0)
OCP or RMC Halt(IRQ0)
Unused
INTR -PCI_ISA Device Interrupt error(IRQ1)
SMI- System Mgmt Interrupt error(IRQ1)
NMI - Non-Maskable Interrupt-fatal error (IRQ1)
Unused
Unused
Environmental Temp,Doors,Fans errors (IRQ1)
Unused
Unused
Pchip1_SLOT5[3:0]-System PCI Slot 9 INTa,b,c,d (IRQ1)
Pchip1_SLOT4[3:0]-System PCI Slot 8 INTa,b,c,d (IRQ1)
Pchip1_SLOT3[3:0]-System PCI Slot 7 INTa,b,c,d (IRQ1)
Pchip1_SLOT2[3:0]-System PCI Slot 6 INTa,b,c,d (IRQ1)
Pchip1_SLOT1[3:0]-System PCI Slot 5 INTa,b,c,d (IRQ1)
Pchip1_SLOT0[3:0]-System PCI Slot 4 INTa,b,c,d (IRQ1)
Pchip0_SLOT4[3:0]-System PCI Slot 3 INTa,b,c,d (IRQ1)
Pchip0_SLOT3[3:0]-System PCI Slot 2 INTa,b,c,d (IRQ1)
Pchip0_SLOT2[3:0]-System PCI Slot 1 INTa,b,c,d (IRQ1)
Pchip0_SLOT1[3:0]-System PCI Slot 0 INTa,b,c,d (IRQ1)
Note:Pchip0_SLOT0 = PCI/ISA Cypress/Acer Bridge
Unused
