35
4.Cylinder head assembly removal
Lift the cylinder head straight up with a hoist.
If the gasket is seized and the cylinder head
cannot be separated from the cylinder block,
tap around the thick side portion of the
cylinder head with a plastic hammer.
5.Valve and valve spring removal
(1)Compress the valve spring with a valve
lifter and remove the valve lock.
(2)Remove the retainer, spring and valve.
The valves, retainers, springs and valve
locks must be set aside separately in groups,
each tagged for cylinder number, for correct
installation.
6.Valve stem seal removal
Remove the valve stem seals with pliers.
Do not reuse the valve stem seals.
