51
(5)Have someone hold the crankshaft pulley
with a wrench to prevent the flywheel
from rotating.
(6)Tighten the four bolts that hold the
flywheel to the specified torque.
Tightening torque
Always signal each other to prevent
possible personal injury.
13.5 0.5 kgf•m
(98 4 lbf•ft)
[132 5 N•m]
10.Rocker shaft assembly installation
(1)Install the valve caps in position on the top
of the valves.
(2)Put the rocker shaft assembly in position
on the cylinder head. Tighten the bolts
that hold the rocker shaft assembly to the
specified torque
1.5 0.5 kgf•m
(11 4 lbf•ft)
[14.7 5 N•m]
11.Valve clearance adjustment
Make reference to“VALVE CLEARANCE”
(page 100)
Tightening torque
12.Rocker cover installation
(1)Make sure the gasket is put on the rocker
cover.
(2)Tighten the bolts that hold the rocker
cover to the specified torque.
1.15 0.15 kgf•m
(8.3 1.1 lbf•ft)
[11.3 1.5 N•m]
Tightening torque
To Next Page
