58
3.Water pump assembly removal
Remove the water pump assembly.
(4)COOLING SYSTEM
DISASSEMBLY REMOVAL
1.Cooling fan removal
Hold the fan by one hand remove the four
bolts that hold the fan in position. Remove the
fan and spacers.
Keep the spacers with the for installation.
2.Thermostat case removal
Remove the thermostat case assembly
containing thermostat.
To Next Page
