60
(6
)AIR INLET AND EXHA
UST SYSTEM
DISASSEMBL
Y REMO
V
AL
1.Exhaust manifold removal
Remove the exhaust manifold from the cylinder
head.
2.Air inlet cover removal
Remove the air inlet cover from the cylinder
head.
(3)Remove the fuel injection pump.
Keep a record of the thickness of shims for
installation.
60
62
