72
(12)LUBLICATION SYSTEM
REINSTALLATION
1.Pressure relief valve installation
Put the relief valve in position on the cylinder
block and tighten in to the specified torque.
2.Oil filter installation
(1)Lightly lubricate the gasket with engine oil.
(2)Install the new filter element by hand.
When the gasket contacts the base, tighten
one turn more.
3.Oil pressure switch installation
Coat the threads of the switch with thread
sealant (Three Bond 1102). Use Oil Pressure
Switch Socket Wrench(MD998054)(special
tool) to install the oil pressure switch.
a)Put the sealant on the threads only.
b)Do not over-tighten the oil pressure
switch when it is installed.
5 0.5 kgf•m
(36 4 lbf•ft)
[49 5 N•m]
Tightening torque
