110
1 4120045 Manifold, intake 1.............................
2 4119959 Gasket 1.....................................
3 2702523 Stud bolt 3...................................
4 4120047 Stud bolt 1...................................
5 2701834 Bolt 6.......................................
6 4120048 Bolt 2.......................................
7 2701914 Nut 4........................................
8 4120049 Body, throttle 1...............................
9 2701995 •Sensor, throttle position 1.....................
10 2701996 •Screw 2....................................
11 2702477 •Sensor, pressure 1...........................
12 2701998 •Screw 6....................................
13 2701999 •Valve, ISC 1.................................
14 2702000 •Gasket 1....................................
15 2701998 •Screw 4....................................
16 2701803 Gasket 1.....................................
17 4120025 Hose, water 1................................
18 4120050 Hose, water throttle inlet 1.....................
19 4116846 Hose, water 1................................
20 4120051 Sensor, inlet air temperature 1..................
21 4120052 Gasket 1.....................................
22 4120100 Hose, water 1................................
23 2702429 Clip 2.......................................
24 2702486 Bolt 1.......................................
25 2702001 Bolt, throttle body 4...........................
26 2702475 Bolt 1.......................................
27 2702431 Plug 1.......................................
Ref.
No.
Part
No.
Description Notes
No.
Req’d
•INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN PRECEDING ASSEMBLY.
CARBURETOR and INTAKE MANIFOLD
(SUZUKI K6A)
