121
AUTOMATIC TRANSMISSION PAN, DIPSTICK and GASKETS
(SUZUKI K6A)
1 2702806 Pan, transmission oil 1.........
2 2702807 Bolt 15.......................
3 2702808 Plug, transmission oil drain 1....
4 2702809 Gasket, plug 1................
5 2702810 Magneto, oil cleaner 1..........
6 2702812 Tube, oil filler (dipstick) 1.......
7 2702813 O--ring 1......................
8 2702475 Bolt 1........................
9 4120110 Oil level gauge 1..............
10 2702816 Solenoid wire harness 1........
11 2702817 Solenoid wire harness hold plate 1
12 2701921 Bolt 1........................
13 2702818 Solenoid wire harness clamp 1..
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
12
13
10
11
9
8
7
6
5
1
4
3
2
Front Of Vehicle
