Cushman 898673 - Transmission Planetary Gears

129
TRANSMISSION PLANETARY GEARS
(AUTOMATIC TRANSMISSION) (SUZUKI K6A)
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
: INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY
1 2702777 Gear, front planetary ring 1......
2 2702778 Bearing set, #3 thrust 1.........
3 2702779 Gear, front planetary 1..........
4 2702780 Bearing set, #4 thrust 1.........
5 2702781 Bearing set, #5 thrust 1.........
6 2702782 Gear, planetary sun 1..........
7 2702783 Washer set, thrust 1............
8 2702784 Gear, rear planetary 1..........
9 2702785 Bearing set, #1 thrust 1.........
10 4120107 Clutch set, one way 1..........
11 4119614 Plate set, 1st/reverse 1.........
12 2702788 Piston set, 1st/reverse 1........
13 2702789 :O-ring set, 1st/reverse 1.......
14 4120108 Retainer, outer race 1..........
Front Of Vehicle
11
13
12
10
14
8
9
7
1
2
4
3
5
6
