125
1 13110-85
X57 Manifold, intake 1..........
2 13119-73001-
H17 Gasket, intake mnfld. 2
3 09246-04005 Plug, boost 1.............
4 01550-08203 Bolt 3....................
5 01411-08203 Stud bolt 4................
6 01411-08253 Stud bolt 1................
7 08316-10083 Nut 5....................
8 11851-62
B00 Hook, engine 1............
9 2700621 Carburetor , complete 1.........
10 13121-80000 Insulator, carburetor 1......
11 13125-80000-
H17 Gasket, carburetor 2...
12 09108-08169 Stud bolt 2................
13 08316-10083 Nut 2....................
14 34850-50
A00 Gauge, water temp. 1......
15 51030-85051 Hose, brake vacuum No. 3 1
16 09401-15404 Clamp 1..................
17 2700621 Carburetor , complete 1.........
18 13270-855
T0 :Screw set, idle adjust 1....
19 09492-47006 :Jet, pilot
(#47.5) 1.........
20 13278-45010 :O-ring 1.................
21 13398-78110 :Plate 1..................
22 02112-75103 :Screw 1.................
23 13260-797
T0 :Solenoid set 1............
24 13250-852
T0 :Float set 1...............
25 13370-60
CT0 :Valve set, needle 1........
26 02112-04087 :Screw 1.................
27 09491-21024 :Jet, main
(#108.8) 1.......
28 13251-79110 :O-ring 1.................
29 13240-852
T0 :W eight set, pump 1.......
30 02142-05163 :Screw 5.................
31 09355-35754 :Hose As Req’d............
32 09492-65005 :Jet, enrichment
(#65) 1....
33 13494-78420 :Spring 1.................
34 02112-34253 :Screw 1.................
35 13380-793
T0 :Gasket set 1.............
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
CARBURETOR & INTAKE MANIFOLD
(SUZUKI 970)
11
10
8
21
9
15
4
20
3
13
25
14
19
17
16
5
6
12
7
18
22
23
24
7
11
2
1
2
: INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY
35
26
27
28
29
30
35
33
35
34
34
31
35
32
Also See Item No. 17
For a Breakdown of
the Carburetor
Front Of Vehicle
No Hose, Just Plug
With Clamp
To Next Page
