128
TRANSMISSION INPUT SHAFT and CLUTCH ASSEMBLY
(AUTOMATIC TRANSMISSION) (SUZUKI K6A)
7
6
5
8
1
2
4
3
Front Of Vehicle
Ref.
No.
Part
No.
Description
No.
Req’d
Description
Part
No.
Ref.
No.
1 2702769 Shaft set, input 1..............
2 2702770 :Plate set, forward clutch 1.....
3 2702771 :O-ring set, forward clutch 1....
4 2702772 Bearing set, thrust
(No. 1) 1.....
5 2702773 Clutch assembly, direct 1.......
6 2702774 :Plate set, direct clutch 1.......
7 2702775 :O-ring set, direct clutch 1......
8 2702776 Washer set, direct clutch 1......
: INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY
To Next Page
