Cushman 898673 - Exhaust System (Suzuki K6 A)

58
EXHAUST SYSTEM (SUZUKI K6A)
1 450193 Screw, M8-1.25 x 30 2...........
2 450378 Locknut, M8-1.25 staytite 2......
3 838295 Strap, muffler hanger 1..........
4 841982 Clamp, exhaust tube (1 1/2”) 1...
5 2700143Ring, muffler flange 1............
6 2700144Bolt, muffler flange 2............
7 2700145Spring, muffler flange 2..........
8 4114221.8 Bracket, muffler 1.............
9 36074--G01 T ube assy, muffler inlet 1.....
10 4119866.8 Muffler assy 1................
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
1
2
3
4
5
6
7
8
9
Front Of Vehicle
