57
FRAME
1 309067 Lockwasher , 1/2 shakeproof 2....
2 450453 Nut, M8-1.25 (G10.9) 3..........
3 450454 Nut, M10-1.50 (G10.9) 40........
4 450455 Nut, M12-1.75 (G10.9) 21........
5 452389 Screw, M8-1.25 x 25 (8.8) 3......
6 452398 Screw, M10-1.50 x 20 (8.8) 27....
7 452402 Screw, M10-1.50 x 50 (8.8) 6.....
8 452403 Screw, M10-1.50 x 60 (8.8) 4.....
9 452405 Screw, M10-1.50 x 80 (8.8) 5.....
10 452410 Screw, M12-1.75 x 30 (8.8) 17....
11 548911 Nut, 5/16-18 1..................
12 800177 Screw, 5/16-18 x 3/4 1...........
13 800279 Nut, speed, 1/4-20 4............
14 800582 Screw, 1/4-20 x 3/4 4............
15 800930 Screw, M8-1.25 x 16 (8.8) 1......
16 841258 Bracket, drawbar 1..............
17 2700796 Panel, console, (turf) 1.........
822819 :Decal, W arning Park Brake 1....
844177 :Decal, auxillary transmission 1...
844179 :Decal, hydraulic controls 1......
2700797 Panel, console, (turf) 1.........
845185 :Decal, W arning Park Brake (EC) 1
844177 :Decal, auxillary transmission 1...
844177 :Decal, auxillary transmission 1...
18 841805 Panel, access 1................
19 842870 Angle, support 2................
20 844601 Bracket, battery clamp 1.........
21 882971 Pin, disconnect 2...............
22 809265 :Pin, hair 25/32 x 2 11/16 1......
23 893145 ROPS, lower 1.................
24 893199.7 Platform, turf 1................
also 893199G Platform, turf (galvanized) 1....
25 893220 Drawbar, turf 1.................
26 893235 Frame, main 1..................
also 893235G Frame, main (galv.) 1..........
27 893487 Fender (left) 1..................
28 893488 Fender (right) 1.................
29 893525 Support, platform 2.............
30 893527 Support, fuel tank 1.............
31 894711 Guard, hydraulic tank 1..........
32 452406 Screw, M10-1.50 x 90 (8.8) 4.....
33 452415 Screw, M12-1.75 x 80 (8.8) 8.....
34 844729 Spacer, battery hold-down 1......
35 844647 Angle, hold-down 1.............
36 810437 Clamp, tube (Suzuki 970) 1......
37 828382 Seal, foam As Req’d.............
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
`
` Item No. 34 (Battery Hold-down Spacer, Part No. 844729) may not be used on all vehicles. If the battery
clamp cannot be adjusted to properly secure the battery, this spacer will be required.
• INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY.
*
Not Illustrated.
*
*
*
*
*
*
(17)
