Cushman 898673 - Page 136

134
Ref.
No.
Part
No.
Description
No.
Req’d
Description
Part
No.
Ref.
No.
1 26500-60HH2 Body assembly
transmission valve 1.......
2 2702822 Solenoid, direct clutch 1....
3 2702823 O--ring 1.................
4 2702824 Solenoid assembly,
2nd brake position 1.......
5 2702823 O--ring 1.................
6 2702764 Bolt, solenoid 2............
7 2702825 Strainer, transmission oil 1..
8 2702826 Bolt, valve body, No. 5 2....
9 2702827 Bolt, valve body, No. 6 3....
10 2702839 Bolt, valve body, No. 1 2....
11 2702840 Bolt, valve body, No. 2 2....
12 26531--67HT0 Piston set, C1 ACC 1......
13 26563--67H10 Spring, ACC
2nd brake position 1.......
14 2702830 Piston set, B1 ACC 1......
15 2702831 Spring, ACC
2nd brake position 1.......
16 26563--67H30 Spring, ACC forward piston 1
17 26533--67HT0 Seal ring set, accumulator 1
18 2702834 Bolt, valve body, No. 2 2...
19 2702835 Bolt, valve body, No. 3 1...
20 2702836 Bolt, valve body, No. 1 6...
21 2702837 Bolt, valve body, No. 4 2...
22 2702838 Bolt, valve body, No. 6 1...
23 2702841 Spring, ACC
2nd brake position No. 2 1..
24 2702842 Spring, ACC
2nd brake position No. 3 1..
TRANSMISSION VALVE
(AUTOMATIC TRANSMISSION) (SUZUKI K6A)
