167
1 120166 Lockwasher , 1/2 1..............
2 181027 Bearing, ball (mm 20 52 15 “OP”) 1
3 301988 Nut, 1/2-20 1...................
4 450324 Nut, M8-1.25 (G8.8) 1...........
5 452380 Bolt, M6-1.00 x 30 (8.8) 1........
6 452381 Screw, M6-1.00 x 40 (8.8) 1......
7 452389 Screw, M8-1.25 x 25 (8.8) 3......
8 452390 Bolt, M8-1.25 x 30 (8.8) 1........
9 452396 Bolt, M8-1.25 x 90 (8.8) 7........
10 548204 Set screw, 3/8-16 x 3/8 1........
11 548477 Washer 6......................
12 800425 Screw, M6-1.00 x 12 (8.8) 1......
13 805307 Washer, 5/8 1..................
14 807624 O-ring 1.......................
15 812419 Shim, transmission 1............
16 815012 Spring 1.......................
17 815013 Button 1.......................
18 815085 Fork, shifter 1..................
19 815182 Gear, PTO sliding 1.............
20 817397 Arm, PTO shifter 1..............
21 844181 Housing, PTO 1................
22 844184 Spacer, 5th gear 1..............
23 844185 Shaft, output 1.................
24 844186 Washer, special 1...............
25 844187 Bearing, ball (.59 1.65 .51 “OP”) 1
26 844906 Seal, tailshaft 1.................
27 879807 Arm assembly, PTO shifter 1.....
28 894947 Shaft, idler 1...................
29 316942 :Pin, spirol 1...................
30 894965 Gear assembly, idler 1...........
31 844182 :Gear, idler 1...................
32 09304-16014 :Bushing, countershaft 2...
33 894989 Housing, bearing 1..............
34 815093 :Bearing, ball (.998 2.05 .59 “OP”)1
35 844188 :Seal, oil 1.....................
36 2700120 Gasket, PTO housing to trans 1.
37 2700121 Gasket, PTO housing 1........
38 09246-16010 Plug, oil fill 2..............
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
MECHANICAL PTO
(SUZUKI 970 and PERKINS DIESEL)
• INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY
37
36
