Cushman 898673 - Page 57

55
BODY, HOOD and HEADLIGHTS
1 303952 Washer, #10 1..................
2 894743 Nut ay., double 1/4-20 2.........
3 306419 Screw, 1/4-20 x 1/2 2............
4 306463 Pin, cotter 1....................
5 38061
A Cap, vinyl 2....................
6 450400 Washer, M8 2..................
7 450410 Lockwasher , M6 2..............
8 450452 Nut, M6-1.00 1.................
9 450541 Screw, M6-1.00 x 16 (RPH) 7....
10 452695 Screw, M6-1.00 x 20, taptite 6....
11 800930 Screw , M8-1.25 x 16 (8.8) 6......
12 800934 Screw, M6-1.00 x 16 (8.8) 25....
13 800943 Screw, tap, #10-14 10...........
14 837303 Headlight, rectangular 2.........
15 2700792 Clip, front 1...................
821071 :Decal, notice not motor vehicle 1.
840901 :Decal, W arning read ops. manual1
16 843854 Hood, turf (green) 1.............
17 841428 Bezel, headlamp 2..............
18 841477 Hinge, hood 1..................
19 841637 Angle, front clip mount 1.........
20 841715 Rod, hood release 1.............
21 841753 Bracket, hood latch 1............
22 841787 Latch, hood 1..................
23 841264 Panel, dash (left) 1..............
844116 Decal, left dash panel, turf 1......
24 841913 Plate, access 2.................
25 74764 Decal,
CUSHMAN 1..............
26 844167 Bracket, horn/brake reservoir 1...
27 74792 Decal, turf-truckster (left) 1.......
28 74766 Decal, turf-truckster (right) 1......
29 886090 Horn 1........................
30 894030 Striker, hood 1..................
31 844669 Seal, weather As Req’d...........
32 306488 Lockwasher , 1/4 shakeproof 2....
33 548159 Washer, 5/16 (1 1/4” diameter) 4..
34 548175 Washer, 1/4 (1 1/4” diameter) 8...
35 800582 Screw, 1/4-20 x 3/4 4............
36 844049 Flap, mud 2....................
37 844293 Plug 3.........................
38 800344 Screw, tapping, #10 type AB 2....
39 823549 Tie, cable, 15.5” (394 mm) 2.....
40 840508 Mount, cable tie 2...............
41 38541 T ube, document 1..............
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
*
*
• INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY.
*
Not Illustrated.
*
