HYDRAULIC BRAKE LINES
1 103867 Washer, 5/16 1.................
2 306328 Pin, cotter, 3/32 x 3/4 1..........
3 450453 Nut, M8-1.25 (G10.9) 1..........
4 450510 Screw, M3-.50 x 20 (G10.9) 2....
5 452388 Screw, M8-1.25 x 20 (8.8) 3......
6 452424 Nut, M3-.50 2..................
7 845380 Hose, 5/16” brake As Req’d.......
8 800934 Screw, M6-1.00 x16 (8.8) 4......
9 806714 Pin, clevis 5/16 x 15/16 1........
10 810152 Cover, brake pedal 1............
11 825624 Clamp, hose 4..................
12 840725 Pin, brake pivot 1...............
13 840726 Bearing, brake pivot 1...........
14 842051 Tube, brake line rear 1..........
15 842103 Union, brake fitting (metric) 1.....
16 842935 Tab, locking 1..................
17 843022 Tube, rear brake 1..............
18 843021 Tube, front brake 1..............
19 844167 Bracket, reservoir mounting 1....
20 892921 Lever, brake 1..................
21 895113 Cylinder, brake (dual) 1..........
22 894167 Rod, brake 1...................
23 894456 Reservoir , brake fluid 1..........
24 890808 Switch, micro 1.................
25 450454 Nut, M10-1.50 (G10.9) 1.........
26 452398 Screw, M10-1.50 x 20 (8.8) 1.....
27 548910 Nut, 1/4-20 1...................
28 800026 Screw, 1/4-20 x 3/4 1............
29 809137 Clip 1.........................
30 810435 Clamp 2.......................
31 800943 Screw, tap #10-14 x 5/8 1........
32 812445 Clamp, tube/wire 1..............
33 841842 Tee, M10-1.00 1................
34 843418 Clamp, tee 1...................
35 452692 Screw, tap M6-1.00 x 12 1.......
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
+
+
The brake hose (Part No. 845380) is serviced as a 6’ (1,829 mm) length.
