Cushman 898673 - Page 71

69
1 120052 Lockwasher , #10 5..............
2 450453 Nut, M8-1.25 (G10.9) 4..........
3 450452 Nut, M6-1.00 (G10.9) 2..........
4 452378 Screw, M6-1.00 x 20 2...........
5 452389 Screw, M8-1.25 x 25 (8.8) 1......
6 452390 Screw, M8-1.25 x 30 (8.8) 2......
7 829954 Gasket 1......................
8 800021 Screw, #10-32 x 1/2 5...........
9 843343 Cap fuel (unvented) 1...........
10 843298 Sender, fuel 1..................
11 821893 Trim, push-on As Req’d...........
12 825624 Clamp, hose 12.................
13 826590 Hose, fuel, 5/16 i.d. As Req’d......
14 829787 Terminal, 45E 1/4 male 2.........
15 829997 Grommet 1....................
16 830425 Hose, fuel, 1/4 i.d. As Req’d.......
17 833953 Cover, fuel sender 1.............
18 834037 Connector , hose 2..............
19 838154 Bracket, fuel pump mounting 1...
20 841969 Tank, fuel 1....................
21 836852
:Breather 1....................
22 84310
:Grommet 2...................
23 843727
:Elbow, 90E 1..................
24 843726
:T ube, fuel pick-up 1............
25 842800 Clamp, filter 1..................
26 893527 Support, fuel tank 1.............
27 894638 Pump, fuel 1...................
28 2208175 Filter , fuel 1...................
29 893555 Strap, fuel tank 1...............
30 103867 Washer, 5/16 1.................
31 800697 Nut, crownlock, 5/16-18 1........
32 450454 Nut, M10-1.50 (10.9) 2..........
33 548911 Nut, 5/16-18 1..................
34 800177 Screw, 5/16-18 x 3/4 1...........
35 452394 Screw, M8-1.25 x 70 (8.8) 1......
36 809231 Grommet 2....................
37 834036 Connector , hose 1..............
38
130306180 Pre-filter, fuel 1...............
39 843534 Bracket, fuel filter 1.............
40 831039 Hose, fuel 5/32 i.d. As Req’d......
41 833851 Seal, foam As Req’d.............
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
: INDENTED PARTS NAME INDICATE THESE PARTS ARE INCLUDED WITH THE PRECEDING ASSEMBLY
FUEL SYSTEM (DIESEL)
Certain engine parts will need to be ordered directly from Perkins. Ref No. 38, Fuel Pre-filter, shows the
Perkin’ s part number and is one of the parts which would be obtained from Perkin’s.
The model and specification numbers for the Perkins engine are as follows:
Model 103.10 - Spec. KD70377.
When ordering from Perkin’ s be sure to include the Engine Model and Spec No’s.
The parts listed below can be ordered from the Cushman Parts Department.
To locate the Perkin’s Dealer nearest to you, please call: 1-888-737-5364
1 842553 Filter, oil 1.....................
2 842555 Gasket, manifold 1..............
3 842235 Gasket, inlet 1..................
4 2208175 Filter, fuel 1...................
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
