Cushman 898673 - Page 77

75
1 302944 Nut, jam, 9/16-18 1.............
2 450077 Bolt, M16-2.00 x 90 2...........
3 450382 Nut, M16-2.00, locking insert 2...
4 450393 Washer, M16 4.................
5 450457 Nut, M16-2.00, flange (G10.9) 2..
6 452398 Screw, M10-1.5 x 20 (8.8) 1......
7 800945 Bolt, M12-1.75 x 60 (G10.9) 2....
8 800485 Nut, 9/16-18, left-hand 1.........
9 800919 Bolt, M10-1.5 x 30 (G10.9) 4.....
10 809137 Clip 1.........................
11 810437 Clamp 4.......................
12 831405 Fitting, grease, 1/4-28 (90E)4....
13 841167 Bushing, silentbloc 4............
14 841404 Rod, tie 1......................
15 844148 Ball joint, upper 1...............
16 841429 Ball joint, lower 1...............
17 817250 Cap, grease 1..................
18 304636 Pin, cotter 1/8 x 1 1/8” 1.........
19 841630 Trunnion, control arm 1..........
20 841737 Shim, .060” 4...................
21 841738 Shim, .024” 2...................
22 841840 Tube, brake (left) 1..............
23 841841 Hose, brake 1..................
24 894573 Knuckle, steering (left) 1.........
25 842104 Bracket, brake tube 1...........
26 887512 End, tie rod (RH thread) 1........
27 306328 :Pin, cotter , 3/32 x 3/4 1.........
548224 :Fitting, lubrication 1............
28 311537 Nut, castle 3/4-16 1.............
29 816586 Retainer, grease 1..............
30 893233 Arm assembly, lower control 1....
31 841430 Drum, brake 1..................
32 800909 Nut, wheel retaining, M12-1.50 5..
33 306328 Pin, cotter, 3/32 x 3/4 2..........
34 306825 Nut, castle, 7/16-20 2...........
35 887750 End, tie rod (LH thread) 1........
36 306328 :Pin, cotter , 3/32 x 3/4 1.........
548224 :Fitting, lubrication 1............
37 311537 Nut, castle 3/4-16 1.............
38 816586 Retainer, grease 1..............
39 893266 Arm assembly, upper control 1....
40 311537 Nut, castle 3/4-16 1.............
41 385174 Bearing, cone (outer) 1..........
42 815403 Bearing, cone (inner) 1..........
43 817928 Seal, grease 1..................
44 893206 Hub assembly 1................
45 808088 :Cup, bearing (outer) 1..........
46 814474 :Cup, bearing (inner) 1..........
47 800908 :Screw, lug M12-1.50 x 42 5.....
48 450452 Nut, M6-1.00 (G10.9) 1..........
49 452378 Screw, M6-1.00 x 20 (G10.9) 1...
50 450455 Nut, M12-1.75 (G10.9) 4.........
51 452413 Screw, M12-1.75 x 60 4.........
52 894635 Strut ay, (shock & spring) 1......
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
*
*
• INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY.
*
Not Illustrated. Although this lubrication fitting is the standard fitting used with this tie rod, it is not used in this
application. Use Ref. No. 12, Part No. 831405.
FRONT SUSPENSION (LEFT SIDE) and TIE RODS
If ordering Ref. No’s. 26 (887512) or 35 (887750) you will also need to order Ref. No. 12 (831405).
