1 302944 Nut, jam, 9/16-18 1.............
2 303269 Lockwasher , 7/16 3.............
3 311392 Screw , 7/16-14 x 2 3............
4 450077 Bolt, M16-2.00 x 90 2...........
5 450382 Nut, locking insert M16-2.00 2....
6 450393 Washer, M16 4.................
7 450457 Nut, M16-2.00, flange (G10.9) 2..
8 452398 Screw, M10-1.5 x 20 (8.8) 1......
9 452408 Screw, M10-1.75 x 20 (G10.9) 6..
10 800945 Bolt, M12-1.75 x 60 (G10.9) 2....
11 452692 Screw , M6-1.00 x 12 1...........
12 800485 Nut, 9/16-18, left-hand 1.........
13 800919 Bolt, M10-1.5 x 30 4.............
14 809137 Clip 1.........................
15 831405 Fitting, grease 1/4-28 (90E)4.....
16 843418 Clamp, tee 1...................
17 841167 Bushing, silentbloc 4............
18 841255 Gear, power steering 1..........
19 841336 Arm, pitman 1..................
20 841404 Rod, tie 1......................
21 844148 Ball joint, upper 1...............
22 841429 Ball joint, lower 1...............
23 304636 Pin, cotter 1/8 x 1 1/8 1..........
24 817250 Cap, grease 1..................
25 841630 Trunnion, control arm 1..........
26 841737 Shim, .060” 4...................
27 841738 Shim, .024” 2...................
28 841839 Tube, brake (right) 1............
29 841841 Hose, brake 1..................
30 841842 Tee, union, M10-1.00 flare 1......
31 842033 Plate, skid 1....................
32 894574 Knuckle, steering (right) 1........
33 842104 Bracket, brake tube 1...........
34 887512 End, tie rod (RH thread) 1........
35 306328 :Pin, cotter , 3/32 x 3/4 1.........
548224 :Fitting, lubrication 1............
36 306825 Nut, castle, 7/16-20 1...........
37 816586 Retainer, grease 1..............
38 893234 Arm assembly, lower control 1....
39 893421 Frame assembly, front 1.........
40 841430 Drum, brake 1..................
41 800909 Nut, wheel retaining, M12-1.50 5..
42 306328 Pin, cotter, 3/32 x 3/4 2..........
43 306825 Nut, castle, 7/16-20 2...........
44 887750 End, tie rod (LH thread) 1........
45 306328 :Pin, cotter , 3/32 x 3/4 1.........
548224 :Fitting, lubrication 1............
46 306825 Nut, castle, 7/16-20 1...........
47 816586 Retainer, grease 1..............
48 810437 Clamp 4.......................
49 893266 Arm assembly, upper control 1....
50 385174 Bearing, cone (outer) 1..........
51 815403 Bearing, cone (inner) 1..........
52 817928 Seal, grease 1..................
53 893206 Hub assembly 1................
54 808088 :Cup, bearing (outer) 1..........
55 814474 :Cup, bearing (inner) 1..........
56 800908 :Screw, lug M12-1.50 x 42 5.....
57 311537 Nut, castle 3/4-16 1.............
58 450452 Nut, M6-1.00, flange (G10.9) 1...
59 452378 Screw, M6-1.00 x 20 1..........
60 450455 Nut, M12-1.75 (G10.9) 12........
61 452413 Screw, M12-1.75 x 60 4.........
62 452415 Screw, M12-1.75 x 80 (8.8) 8.....
63 894635 Strut ay. (shock & spring) 2......
Ref.
No.
Part
No.
Description
No.
Req’d
No.
Req’d
Description
Part
No.
Ref.
No.
*
*
FRONT SUSPENSION (RIGHT SIDE) TIE RODS and SKID PLATE
• INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN THE PRECEDING ASSEMBLY.
*
Not Illustrated. Although this lubrication fitting is the standard fitting used with this tie rod, it is not used in this
application. Use Ref. No. 15, Part No. 831405.
If ordering Ref. No’s. 34 (887512) or 44 (887750) you will also need to order Ref. No. 15 (831405).
