CYG PRS-7367 User Manual

Protection Functions
PRS-7367 127
No.
Name
Values(Range)
Unit
Step
Default
Description
instantaneous protection
0: disable
1: enable
5
79AR_UnsucBlk
0 ~1
-
1
0
Enabling/disabling block AR at
unsuccessful reclosing
0: disable
1: enable
6
79AR_AutoRst
0 ~1
-
1
1
Enabling/disabling auto reset the blocked
status
0: disable
1: enable
7
79AR_Circle_N
1~4
1
4
Maximum number of reclosing attempts
8
79AR_T_CBclosed
0.00~600.00
s
0.01
5
Time delay of circuit breaker in closed
position before reclosing
9
79AR_T_CBhealthy
0.00~600.00
s
0.01
5
Time delay to wait for CB healthy.
10
79AR_T_TrFail
0.10~5.00
s
0.01
0.5
Time delay that protection trip signal can
last for
11
79AR_T_DeadTimeH
0.10~10.00
s
0.01
0.1
Dead time of high speed startup (first
instantaneous time shot 3-pole reclosing)
at first shot
12
79AR_T_DeadTime1
0.10~600.00
s
0.01
1
Dead time of time delayed startup at first
shot 3-pole reclosing
13
79AR_T_DeadTime2
0.10~600.00
s
0.01
1
Dead time of time delayed startup at
second shot 3-pole reclosing
14
79AR_T_DeadTime3
0.10~600.00
s
0.01
1
Dead time of time delayed startup at third
shot 3-pole reclosing
15
79AR_T_DeadTime4
0.10~600.00
s
0.01
1
Dead time of time delayed startup at forth
shot 3-pole reclosing
16
79AR_T_Pluse
0.10~5.00
s
0.01
0.2
Pulse width of 79AR closing signal
17
79AR_T_WaitSyn
0.05~60.00
s
0.01
10
Maximum wait time for synchronism
check
18
79AR_T_WaitNext
0.00~10.00
s
0.01
0
Wait time of next reclosing
19
79AR_T_Reclaim
0.10~900.00
s
0.01
10
Reclaim time
20
79AR_T_Unsuc
0.05~10.00
s
0.01
2
Maximum wait time for circuit breaker
closing before indicating unsuccessful
3.23 Synchronism check 25SYN
3.23.1 Overview
The synchronization checking function 25SYN ensures that the grid can be merged at the right
