Technical Specifications
26 PRS-7367
Electromagnetic fields
immunity
IEC 60255-26, IEC
61000-4-3
Test Field Strength: 10V/m , Sweep frequency:
80MHz – 1000MHz, Spot frequency: 80MHz,
160MHz, 450MHz, 900MHz @ 80% Modulation &
Pulse
immunity to conduct,
common mode disturbance
in frequency range 0 Hz to
150KHz
61000-4-16
Level 4：continuous 30V,short duration 300V at
50/3,50,60Hz; 15Hz~150Hz:30-3 decreases at
20dB/decade; 150Hz~1.5kHz:3 constant;
1.5kHz~15kHz:3-30 increases at 20dB/decade;
15kHz~150kHz:30 constant
power frequency magnetic
fields
IEC 61000-4-8, IEC
60255-26
Continuous: 100A/m, Short Duration 1s to 3s:
1000A/m)
Pulse magnetic field
immunity test
IEC 61000-4-9
Class 5: Current 6.4/16µs, 1000A/m
Damped oscillatory
magnetic field immunity
test
IEC 61000-4-10
Class 5: 0.1MHz&1MHz, 100A/m
Power frequency immunity
tests
IEC 60255-26
Input: Class A, Common Mode: 300V, Differential
Mode: 150V
Ring wave immunity test
IEC 61000-4-12
Ring Wave Class 4,4kV
Conducted RF interference
on power supply terminals
IEC 60255-26, CISPR 22
Conducted Emission Limit for Auxiliary Power
Supply Port：Frequency range: 0.15MHz – 0.5MHz
(Quasi Peak: 79µV, Avg: 66µV), Frequency range:
0.5MHz – 30MHz (Quasi Peak: 73µV, Avg: 60µV)；
Radiated interference
IEC 60255-26, CISPR 22
Radiated Emission Limit on Enclosure Port ：
Frequency range: 30MHz - 230MHz (Quasi Peak:
40µV), Frequency range: 230MHz - 1000MHz
(Quasi Peak: 47µV)
2.6 Terminals
Connection Type
Wire Size
CT and VT circuit connections
Screw terminals,4mm
2
lead
Binary I/O connection system
Screw terminals, 2.5mm
2
lead
