CYG PRS-7367 - Communication Interfaces

Technical Specifications
PRS-7367 23
Operating temperature range
-25°C ~ +70°C
Transport and storage temperature
range
-40°C ~ +70°C
Damp heat steady
+40℃ 93%humidity 16h
Damp-heat test, cyclic
6 cycles, +25℃ to +55℃, Humidity 97% to 93%
2.4 Communication Interfaces
2.4.1 Ethernet Port
Medium
Parameters
Ethernet:
Electrical OR
Optical
Electrical
Port number
3
Connector type
RJ-45
Transmission rate
100Mbits/s
Transmission standard
100Base-TX
Transmission distance
≤ 100m
Protocol
IEC60870-5-103:1997, IEC61850 etc.
Safety level
Isolation to ELV level
Optical
Port number
3
Connector type
LC
Transmission rate
100Mbits/s
Transmission standard
100Base-FX
Optical fiber type
Multi-mode
Wavelength
1310nm
Transmission distance
≤ 2000m
Protocol
IEC60870-5-103:1997, IEC61850 etc.
2.4.2 Serial Port
Medium
Parameters
RS-485 (EIA)
Port number
2
Baud rate
4800 ~ 115200bps
Transmission distance
≤ 500m @ 4800bps
Maximal capacity
32
Protocol
IEC60870-5-103:1997, DNP3.0 etc.
Safety level
Isolation to ELV level
2.4.3 Time Synchronization
Medium
Parameters
RS-485 (EIA)
Port number
1
Transmission distance
≤ 500m
Maximal capacity
32
Timing standard
IRIG-B
Safety level
Isolation to ELV level
Optical Ethernet
Port number
1
Transmission distance
≤ 2000m
