CYG PRS-7367 User Manual

Supervision Functions
PRS-7367 235
Table 4.2-1 Alarm Signal and Block
Alarm Signal Name
Block Protection or Not
Kernel Comm Abn
YES
Databus Comm Intr
YES
Databus Data Abn
YES
LVDSIO Input Err
YES
LVDSBus SelfChk Abn
YES
Comp SelfChk Abn
YES
RAM Scan Err
YES
Sys Const SelfChk Abn
YES
SelfChk Comp Port Err
YES
SelfChk Comp Cfg Err
YES
Setting SelfChk Err
YES
Setting CRC Err
YES
Soft Sw SelfChk Err
YES
Soft Sw CRC Err
YES
BO Cfg SelfChk Err
YES
BO Cfg CRC Err
YES
Para SelfChk Err
YES
Para CRC Err
YES
Prot Comp RAM Scan Err
YES
Databus LongTime Losing Pkg
NO
Databus Wrong Pkg Alarm
NO
A/D Sampling Err
NO
IRIG-B Syn Abn
NO
Mana Bus Comm Intr
NO
Setting Set CRC Err
NO
Soft Sw Set CRC Err
NO
Para Set CRC Err
NO
Main Cfg Check Abn
NO
Cfg File Check Abn
NO
Comp Cfg Check Err
NO
WaveRcd Cfg File Abn
NO
WaveRcd File Abn
NO
4.3 Current circuit supervision CTS
4.3.1 CTS Overview
The main purpose of the current circuit supervision function is to detect faults in the secondary
circuits of the current transformer and avoid influence on the operation of relevant protection
functions. This current circuit supervision function will be in operation at any time, whether the
general fault detection picks up or not.
