CYG PRS-7367 User Manual

Protection Functions
126 PRS-7367
SYNC_25
U3P
ChkOK
DLDBOK
DLLBOK
LLDBOK
DdChkOK
VolDiffOK
FrDiffOK
AngDiffOK
Ux
Blk
SynChkBlk
DdChkBlk
SynChkOK
UsynVTSAlm
UsynPhsAlm
CB_Open
Figure 3.22-15 three times fault happen in two shot AR
3.22.3 Settings
Table 3.22-4 79AR Settings
No.
Name
Values(Range)
Unit
Step
Default
Description
1
79AR_Enable
0 ~1
-
1
0
Enabling/disabling auto-reclosing
0: disable
1: enable
2
79AR_ExtCtrl
0 ~1
-
1
0
Enabling/disabling AR by external input
signal besides logic setting 79AR_Enable
0: only logic setting
1: logic setting and external input signal
3
79AR_CBStr
0 ~1
-
1
0
Enabling/disabling 79AR be initiated by
open state of circuit breaker (three phase)
0: disable
1: enable
4
79AR_BlkInstPro
0 ~1
-
1
0
Enabling/disabling 79AR Block
