CYG PRS-7367 User Manual

Technical Specifications
22 PRS-7367
Pickup voltage
55% ~ 70% rated voltage
“ON” value voltage
70% ~ 120% rated voltage
“OFF” value voltage
< 55% rated voltage
Maximum permitted voltage
120% rated voltage
Resolution of binary input signal
≤ 1ms
Resolution of SOE
≤ 1ms
2.1.5 Binary Output
Reference
IEC 60255-1
Item
Tripping output
Signal output
Binary output number
Up to 34
Up to 34
Output model
Potential-free contact
Potential-free contact
Max system voltage
380Vac, 250Vdc
380Vac, 250Vdc
Voltage across open contact
1000V RMS for 1min
1000V RMS for 1min
Continuous carry
10.0A @ 380Vac；
10.0A @ 250Vdc
5.0A @ 380Vac；
5.0A @ 250Vdc
Short duration current
30A, 3s
50A, 1s
30A, 1s
Breaking capacity
1.00A @ 48Vdc, L/R=40ms
0.35A @ 110Vdc, L/R=40ms
0.30A @ 125Vdc, L/R=40ms
0.20A @ 220Vdc, L/R=40ms
0.15A @ 250Vdc, L/R=40ms
0.60A @ 48Vdc, L/R=40ms
0.10A @ 110Vdc, L/R=40ms
0.05A @ 220Vdc, L/R=40ms
Pickup time
< 5ms
< 10ms
Dropout time
< 5ms
< 8ms
2.2 Mechanical Specifications
Mounting Way
Flush mounted
Weight per device
Approx. 7.0kg (fully equipped)
Mechanical size
(width×high×deepth)
186.8mm*271 mm *209.7 mm
Hole size (width×high)
154 mm *268 mm
Display language
Optional: Chinese, English
Housing material
Metallic plates, parts and screws: Steel
Plastic parts: Polycarbonate
Housing color
Silver grey
Location of terminal
Rear panel of the device
Protection class
IEC60225-1: 2009
Front side: IP40 (IP52 with seal strip)
Rear side, connection terminals: IP20
Other Sides: IP40
2.3 Ambient Temperature and Humidity Range
Standard
IEC 60255-1:2009

CYG PRS-7367 Specifications

General

Brand	CYG
Model	PRS-7367
Category	Control Unit
Language	English
