CYG PRS-7367 User Manual

Monitoring & Control
252 PRS-7367
NO
Name
Range
Unit
Step
Description
5
25SYNC_SYNCHK
0 or 1
Enabling/disabling synchronism check
0: disable
1: enable
6
25SYNC_CLSLOOP
0 or 1
Enabling/disabling closing loop check
0: disable
1: enable
7
25SYNC_FORBID_LOOP
0 or 1
When synchronism check enable, it
will disable closing loop check
8
25SYNC_NOVOL_TDELAY
0 .000~ 10.000
S
0.00
1
Dead check signal and exit delay
parameters
9
25SYNC_LOOP_TDELAY
0 .000~ 10.000
S
0.00
1
Loop check signal and exit delay
parameters
10
25SYNC_VOL_SEL
0 ~ 5
Set Sync Vol Chosen
0~2:UA/UB/UC
3~5:UAB/UBC/UCA
11
25SYNC_SYNOV
57.74~200.00
V
0.01
Threshold of over voltage for
synchronism blocking
12
25SYNC_SYNUV
0.00~57.74
V
0.01
Threshold of under voltage for
synchronism blocking
13
25SYNC_SYNOF
50~70
Hz
0.01
Threshold of over frequency for
synchronism blocking
14
25SYNC_SYNUF
30~50
Hz
0.01
Threshold of under frequency for
synchronism blocking
15
25SYNC_SYS_VOL
0~120
V
0.01
Set Bus Side Rated Voltage Value
16
25SYNC_SYN_VOL
0~120
V
0.01
Set Line Side Rated Voltage Value
17
25SYNC_SAME_FR
0~0.5
Hz
0.01
Frequency difference limit of same
frequency system check
18
25SYNC_DEALIN_VAL
0.01~120.00
V
0.01
Voltage threshold of dead check
19
25SYNC_VOL_VAL
0.01~120.00
V
0.01
Voltage threshold of live check
20
25SYNC_ANG_DIF
1~ 180
deg
0.01
Phase difference limit of synchronism
check
21
25SYNC_VOL_DIF
0.01~100.00
V
0.01
Voltage difference limit of
synchronism check
22
25SYNC_FR_DIF
0.00~2.00
Hz
0.01
Frequency difference limit of
synchronism check
23
25SYNC_DFDT_DIF
0.00~2.00
Hz/
S
0.01
Frequency change rate of
synchronism check
