Hardware
280 PRS-7367
19
20
21
22
23
24
25
26
27
28
29
30
31
32
BO01
Common
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
IO
17
18
BO01
Open
BO02
Common
BO02
Open
BO03
Common
BO03
Open
BO04
Common
BO04
Open
BO05
Common
BO05
Open
BO06
Common
BO06
Open
BO06
Cls
BO07
Common
BO07
Open
BO07
Cls
BI01+
BI02+
BI01~02
Common-
BI03+
BI04+
BI03~04
Common-
BI05+
BI05-
BI06+
BI06-
BI07+
BI07-
BI08+
BI08-
BI09+
BI09-
Figure 6.8-1Frame of the IO Module Terminal
The terminal definition of the IO module is described as below.
Table 6.8-1 Terminal Definition and Description of IO Module
Name
Description
BI01+
The No.1 and No.2 programmable binary input.
BI02+
BI01~ BI02-
BI03+
The No.3 and No.4 programmable binary input.
BI04+
BI03~ BI04-
BI05+
The No.5programmable binary input.
BI05-
BI06+
The No.6 programmable binary input.
BI06-
BI07+
The No.7 programmable binary input.
