/ Event / Records
Fault Events
2001-01-04 01:17:22.693ms
0001/0002
51P1_Op Esc
Phase :
Time : - - ms FaultNo.:00000
Slot3 Not Reverted
01
02
03
04
05
06
07
08
09
Figure 7.3-12 Overview Display of Fault Events
7.3.4.2 Alarm Records
This section divided into two sub-functions like warning records and selfchk Info see figure 7.3.11.
This devise can save latest 1024 alarm records.
1- Warning Records
In this section user can see all warning records like protection warning records and TimingErr
warning records etc. User can access this function through the following path: “Event > Alarm
Records”. The overview display of warning record is shown in below figure 7.3.13.
/ Event / Alarm Records
Warning Records
2018-04-11 12:17:22.693ms
0003 0022
TimingErr Act
Phase : FaultNO.:00001
Slot3 Not Reverted
Figure 7.3-13 Overview Diagram of Warning Records Info
2- Selfchk Info
