8 Configurable Function
8.1 General Description
Each product has different configuration parameters according to the functions it has been
designed to perform. There is a common methodology used across the entire product series to set
these parameters.
The IED is equipped with flexible and powerful configuration functions, including the system
configuration, the protection logic configuration, the binary input configuration, the binary output
configuration, the setting groups selection and the LED indicator configuration through the
auxiliary software, which makes this IED meet various practical requirements.
8.2 PRS IED Studio Software
The PRS IED Studio software is developed in order to meet customer's demand on functions of
the UAPC platform device, such as device configuration and programmable design. It selects
substation as the core of data management and the device as fundamental unit, supporting one
substation to supervise many devices.
The software provides two kinds of operation modes: on-line mode and off-line mode. The on-line
mode supports the Ethernet connection with the device through the standard IEC60870-5-103 and
can be capable of uploading and downloading the configuration files through Ethernet net, can
monitor relay parameters and status; the off-line mode supports the off-line setting configuration,
including protection logic programming, the binary input configuration, the binary output
configuration and etc.
The software provides Online and Off-line comparison function, contain the setting and logic
comparison. Online comparison can compare relay configuration and PC backup configuration.
Off-line comparison can compare two devices off-line configuration.
8.3 Setting Group Selection
You can select the setting group using binary inputs. You can choose binary inputs through the
configuration tool, different binary inputs correspond to different setting groups. You can set the
setting group with binary inputs according to the following table:
Table 8.3-1 Recording Time Settings
