Figure 4-150
Select direction, and then input customized rule name.
Name: Input customized rule name.
Action: You can set intrusion action: appear/cross.
Direction (Entry/Exit/Both): System can generate an alarm once there is any object crossing in the
specified direction.
Target filter: Click , you can set filter object size. Each rule can set two sizes (min size/max size).
Once the object is smaller than the min size or larger than the max size, there is no alarm. Please
make sure the max size is larger than the min size.
Now you can draw a rule. Left click mouse to draw a warning zone. Right click mouse to complete the
setup.
Tips
Click to delete the corresponding rule.
Click , you can refer to chapter 4.15.3.1 to set other parameters.
Click Apply to complete the setup.
4.15.3.3 Abandoned Object Detect (Optional)
System generates an alarm when there is abandoned object in the specified zone.
From main menu->Setting->Event->IVS, click Add button and then select the type as abandoned object.
The object interface is shown as below. See Figure 4-151.
