Input the device IP you want to manage in the MG-SOFT MIB Browser. Please set the
corresponding version for your future reference.
Open the tree list on the MG-SOFT MIB Browser; you can get the device configuration. Here you
can see the device has how many video channels, audio channels, application version and etc.
5.5.2.12 Multicast
From main window->Setup->Network->Multicast, the multicast interface is shown as in Figure 5-54.
Multicast is a transmission mode of data packet. When there is multiple-host to receive the same data
packet, multiple-cast is the best option to reduce the broad width and the CPU load. The source host can
just send out one data to transit. This function also depends on the relationship of the group member and
group of the outer.
Figure 5-54
Please refer to the following sheet for detailed information.
The multicast IP address (0.0.0.0～255.255.255.255).
The multicast port value(1025～65000).
Use WEB to login, you can see the following interface. See Figure 5-55. Select login type as the Multicast
from the dropdown list. After you logged in the Web, the Web can automatically get multiple cast address
and add it to the multiple cast groups. You can enable real-time monitor function to view the video.
Figure 5-55
