From main menu->Setup->Event->IVS->Intrusion, the intrusion interface is shown as below. See Figure
5-73.
Figure 5-73
Click to add the rule and select the rule type as Intrusion, check the Intrusion box to enable intrusion
function.
Tips
Double click to change the rule name.
Action: It is to set intrusion mode.
Cross: It includes enter the warning zone, leave the waring zone or cross the warning zone.
Appear: An object falling from nowhere (such as from the sky). It may not fully enter the warning
zone.
Direction: When the action mode is cross, there are three options: A->B, B->A, both. System can
generate an alarm once there is any object enter/exit (Or both) the zone.
Now you can draw a rule. Left click mouse to draw a line first and then right click mouse to draw another
line until you draw a rectangle, you can right click mouse to exit.
Click to draw filter object. Select the blue line and then use mouse to adjust zone size.
Note
Each rule can set two sizes (min size/max size). Once the object is smaller than the min size or
larger than the max size, there is no alarm. Please make sure the max size is larger than the min
